Fits:
Make | Model | Year | Note |
---|
Polaris | Big Boss 500 6x6 | 1998-1999 | |
Polaris | Magnum 500 4X4 | 1999 | |
Polaris | Magnum 500 4X4 | 2000 | Fits model S# 00-01960 and before. |
Polaris | Ranger 500 6x6 | 1999 | |
Polaris | Scrambler 500 4X4 | 1997-1999 | |
Polaris | Scrambler 500 4X4 | 2000 | Fits model S# 00-01960 and before. |
Polaris | Sportsman 500 4X4 | 1998-1999 | |
Polaris | Sportsman 500 4X4 | 2000 | Fits model S# 00-01960 and before. |
Polaris | Sportsman 500 6x6 | 2000 | Fits model S# 00-01960 and before. |
Polaris | Sportsman 500 6x6 | 2001 | |
Polaris | Worker 500 | 1999 | |
Specifications |
---|
Compatible Brand: | Fits Polaris |
Internal Diameter (mm): | 51 |
External Diameter (mm): | 114 |
Thickness (mm): | 20 |
Number of wires: | 9 |
Number of connectors: | 7 |
Number of terminals: | 10 |
Notes: | N/A |
Number: | 285649 |
Product Features
- Direct replacement to your original unit
- Plug-and-play, direct fit, easy installation
- Highest grade lamination materials
- Highest grade copper windings, resistant to 200 degrees Celsius
- Connector included
- Rubber grommet included
- All products shipped are tested
Note: Battery condition is extremely important. No stator can work correctly with a bad or weak battery. Always fully charge your battery before performing any charging system tests or replacing parts. If there is any doubt, have the battery load tested or replaced.
